|B||Seat Collar to Center of Rails||150mm|
|D||Min. Insertion Length||100mm|
|E||Full Insertion Length||217mm|
Routing Method: External
Stanchion Diameter: 22mm
Seatpost Material: 7075 Alloy
Lever Compatability: Compatible with all PNW levers and most cable actuated levers from other brands.
Cable and Housing: Cable and housing included only with the purchase of a lever kit.
The minimum rider weight to actuate post is 44lbs (20kg). The maximum rider weight supported at full post extension is 110lbs (50kg).
Because the Fern is externally routed it's compatible with a lot of frames. Next step is the measurement part! Need help determining the best dropper for you? Click here >>>
We include our cable and housing kits with each of our levers. When you order the dropper by itself cable and housing will not be included.
As riding frequency and conditions vary, we do not have a strict service interval. Instead, we recommend servicing your post if it starts to feel sticky/slows down. When it does come down to service it is a quick and easy, at home process. Check out our service video's here.
